2 CONFIGURATION
The DALIBOX Interface 64/32 application program allows controlling up to 64 DALI
ballasts divided into up to 32 groups. Such control is performed according to a set of
customisable options which make DALIBOX Interface 64/32 a very versatile device:
Different alternatives to control the luminosity of the connected loads:
➢ One-bit objects to switch on / switch off each group,
➢ Four-bit objects for per-group step dimming,
➢ One-byte (percentage) objects for absolute dimming (per group).
General dimming features:
➢ Configurable dimming times, being possible to modify them through
communication objects. Up to three different dimming times are available.
➢ Configurable regulation type. Logarithmic and linear regulation are
available.
➢ Dimming limits, i.e., maximum and minimum lighting levels.
➢ Minimum luminosity level reachable by each group, i.e., the ballast
physical minimum.
➢ Maximum luminosity level allowed in the ballasts under the economy mode.
➢ Standby: mode that allows an external actuator to interrupt the power
supply to the ballasts after switching off the loads, thus reducing the power
consumption.
Custom on/off: possibility of enabling and configuring different switch-on/off
controls for each group, with custom dimming values and times.
Simple timer and flashing: sequence of timed switch-on and switch-off of the
ballasts connected to the device.
Scenes: up to 32 different customisable scenes, which can be simultaneously
associated to different groups.
