[ECG N] Converter Test Result: Returns the result of the last converter test
with the following coding:
HS: Hardware Status. Indicates hardware status:
0: Hardwired Inhibit is activated.
1: Hardwired switch is on: digital input that the converter can have to switch its
light on or off when normal mode is activated.
2 - 3: Reserved.
FP, DP y PP: Function Test Pending / Duration Test Pending / Partial Duration Test
Pending. Indicates if there are any pending test:
0: Unknown.
1: No function, duration, partial duration test pending.
2: Function, duration, partial duration test pending.
3: Reserved.
CF: Converter Failure. Indicates if there are any failure:
0: Unknown.
1: No failure detected.
2: Failure detected.
3: Reserved.
LTRF, LTRD, LTRP: Last Test Result Functional / Duration / Partial duration: Indicates
the test result of each type:
0: Unknown.
1: Passed in time.
2: Passed max delay exceeded.
3: Failed, test executed in time.
4: Failed, max delay exceeded.
5: Test manually stopped.
6 - 15: Reserved.
SF, SD, SP: Start method of last Functional / Duration / Partial test. Indicates the
method by which the last test started. Updated when a test is finish.
0: Unknown.
1: Started automatically.
2: Started by Gateway.
3: Reserved.
