Switch On/Off (1 bit):
➢ Switch-On Value [Last On Value / Defined Value]: allows selecting the
general dimming level that will be adopted by the group when the value “1”
is received through “[Group n] On/Off”. The dimming level will be applied
when sending a switch on value, with the group switched on or off.
• In case of selecting “Last On Value”:
o Reach maximum after a switch-on order if it is already on
[enabled/disabled]: when enabling this option, if the group is
already switched on when receiving the value “1", the dimming
level will reach the maximum configured value.
• In case of selecting “Defined Value”:
o Value [0…100] [%].
➢ On/Off Dimming Time [At Once / Dimming Time 1 / Dimming Time 2 /
Dimming Time 3].
Relative Dimming (4 bits): allows setting up the configuration of the relative
dimming function and the four-bit object “[Group n] Relative Dimming”.
➢ Relative Dimming Time [At Once / Dimming Time 1 / Dimming Time 2 /
Dimming Time 3].
➢ Allow Switching Off via Relative Dimming [enabled/disabled]: sets
whether the group should be switched off in case a decrease order with a
dimming value lower than the minimum value parameterised is received.
Absolute Dimming (1 byte): this section allows setting up the configuration of
the relative absolute dimming function and the one-byte object “[Group n]
Absolute Dimming”.
➢ Absolute Dimming Time [At Once / Dimming Time 1 / Dimming Time 2 /
Dimming Time 3].
