Although the behaviour of the LEDs can be configured independently for each control,
it is also possible to define a general behaviour for all of them thus not being then
necessary to configure the same option multiple times.
In case of opting for a general configuration, the options are:
Regular.
State-Dependent (where available). Functions where “state-dependent” is
not available will use the regular illumination.
State-Dependent (where available) (both LEDs). Functions where “state-
dependent” is not available will use the regular illumination.
Dedicated Object. One binary communication object per control will be
included in the project topology so that the LED of every control turns on/off
depending on its own object.
ETS PARAMETERISATION
For details on the parameterisation of the LED illumination modes please refer to the
pages that cover the specific function being assigned to the button (see section 2.2).
In case of desiring a similar behaviour for all of the LEDs, please find the parameter
LED Illumination Control (All buttons) in the options of the “GENERAL”
configuration.
