13
1 Bit
I
C - - W -
DPT_Switch
0/1
[General] Welcome Back Object - Additional
Condition
Additional Condition Object 5
15
1 Bit
I
C - - W -
DPT_Enable
0/1
[General] Proximity Sensor
0 = Disable; 1 = Enable
16
1 Bit
I
C - - W -
DPT_Ack
0/1
[General] External Proximity Detection
1 = Detection
17
1 Bit
C T - - -
DPT_Ack
0/1
[General] Proximity Detection
Send 1 when Proximity is Detected
18
1 Bit
C T - - -
DPT_Bool
0/1
[General] Luminosity (1-Bit)
0 = Over Threshold; 1 = Under Threshold
1 Bit
C T - - -
DPT_Bool
0/1
[General] Luminosity (1-Bit)
0 = Under Threshold; 1 = Over Threshold
19
1 Byte
O
C - R - -
DPT_Scaling
0% - 100%
[General] Luminosity (Percentage)
0% ... 100%
21
1 Bit
I
C T - W U
0/1
[General] Backlight Mode
0 = Night Mode; 1 = Normal Mode
1 Bit
I
C T - W U
0/1
[General] Backlight Mode
0 = Normal Mode; 1 = Night Mode
22
1 Byte
I
C T - W U
DPT_Scaling
0% - 100%
[General] Display - Brightness
0% ... 100%
23
1 Byte
I
C T - W U
DPT_Scaling
0% - 100%
[General] Display - Contrast
0% ... 100%
24, 30, 36, 42,
48, 54, 60, 66
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] Switch
Send Selected Value on Short Press
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] Hold & Release
Send Selected Values on Hold and Release Presses
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] Two objects - Short Press
Send Selected Value on Short Press
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Ix] Light - On/Off
(Short Press) Switch Between On and Off
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Ix] Shutter - Stop/Step
(Short Press) 0 = Stop Shutter/Step Up; 1 = Stop
Shutter/Step Down
1 Bit
C T - - -
DPT_Trigger
0/1
[Btn][Ix] Shutter - Stop
(End Pressing) Stop Shutter
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Ix] Shutter - Stop/Step
(Short Press) Stop Shutter/Step Up
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Ix] Shutter - Stop/Step
(Short Press) Stop Shutter/Step Down
24, 30, 36, 42,
48
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Ix] Light - On
(Short Press) Send On
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Ix] Light - Off
(Short Press) Send Off
25, 31, 37, 43,
49, 55, 61,
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Ix] Light - Dimming
(Long Press) Switch Between Dimming Up and Down
25, 31, 37, 43,
49
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Ix] Light - Dimming
(Long Press) Dimming Up
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
[Btn][Ix] Light - Dimming
(Long Press) Dimming Down
