Zennio FLAT - Page 48

Flat & Flat 55
http://www.zennio.com Technical Support: http://support.zennio.com
48
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
26, 32, 38, 44,
50, 56, 62, 68
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Long Press) 0 = Up ; 1 = Down
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Start Pressing) Switch Between Up and Down
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] Two objects - Long Press
Send Selected Value on Long Press
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Long Press) Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Long Press) Down
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Start Pressing) Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Ix] Shutter - Move
(Start Pressing) Down
27, 33, 39, 45,
51, 57, 63, 69
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] LED On/Off
0 = Off; 1 = On
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Ix] LED On/Off
0 = On; 1 = Off
28, 34, 40, 46,
52, 58, 64, 70
1 Byte
I
C T - W -
DPT_Scaling
0% - 100%
[Btn][Ix] Scaling
Send Selected Percentage Value on Short Press
1 Byte
I
C T - W -
DPT_Value_1_Ucount
0 - 255
[Btn][Ix] Counter - 1-Byte Unsigned
Send Selected Value on Short Press
1 Byte
I
C T - W -
DPT_Value_1_Count
-128 - 127
[Btn][Ix] Counter - 1-Byte Signed
Send Selected Value on Short Press
2 Bytes
I
C T - W -
DPT_Value_2_Ucount
0 - 65535
[Btn][Ix] Counter - 2-Byte Unsigned
Send Selected Value on Short Press
2 Bytes
I
C T - W -
DPT_Value_2_Count
-32768 - 32767
[Btn][Ix] Counter - 2-Byte Signed
Send Selected Value on Short Press
2 Bytes
I
C T - W -
9.xxx
-671088.64 -
670760.96
[Btn][Ix] Float
Send Selected Value on Short Press
1 Byte
I
C T - W -
DPT_Value_1_Ucount
0 - 255
[Btn][Ix] Two objects - Short Press (1-Byte)
Send Selected 1-Byte Value on Short Press
1 Byte
I
C T - W -
DPT_Scaling
0% - 100%
[Btn][Ix] Shutter - Position
0 - 100 %
1 Byte
I
C T - W -
DPT_Scaling
0% - 100%
[Btn][Ix] Light - Dimming (Status)
0 - 100 %
1 Byte
I
C T - W -
0/1/2
[Btn][Ix] Room State
0 = Normal; 1 = Make-up Room; 2 = Do not Disturb
29, 35, 41, 47,
53, 59, 65, 71
1 Byte
I
C T - W -
DPT_Value_1_Ucount
0 - 255
[Btn][Ix] Two objects - Long Press (1-Byte)
Send Selected 1-Byte Value on Long Press
72, 78, 84, 90
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Switch
Left = 0; Right = 1
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Short Press
Left = 1; Right = 0
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Short Press
Left = 0; Right = 1
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Px] Light - On/Off
(Short Press) Left = Off; Right = On
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Px] Shutter - Stop/Step
(Short Press) Left = Stop/Step Down; Right =
Stop/Step Up
1 Bit
C T - - -
DPT_Trigger
0/1
[Btn][Px] Shutter - Stop
(End Pressing) Left = Stop-Down; Right = Stop-Up
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Switch
Left = 1; Right = 0
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Px] Light - On/Off
(Short Press) Left = On; Right = Off
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Px] Shutter - Stop/Step
(Short Press) Left = Stop/Step Up; Right =
Stop/Step Down
1 Bit
C T - - -
DPT_Trigger
0/1
[Btn][Px] Shutter - Stop
(End Pressing) Left = Stop-Up; Right = Stop-Down
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Switch
Lower = 0; Upper = 1
