Zennio FLAT - Page 49

Flat & Flat 55
http://www.zennio.com Technical Support: http://support.zennio.com
49
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Switch
Lower = 1; Upper = 0
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Px] Light - On/Off
(Short Press) Lower = Off; Upper = On
1 Bit
C T - - -
DPT_Switch
0/1
[Btn][Px] Light - On/Off
(Short Press) Lower = On; Upper = Off
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Px] Shutter - Stop/Step
(Short Press) Lower = Stop/Step Down; Upper =
Stop/Step Up
1 Bit
C T - - -
DPT_Step
0/1
[Btn][Px] Shutter - Stop/Step
(Short Press) Lower = Stop/Step Up; Upper =
Stop/Step Down
1 Bit
C T - - -
DPT_Trigger
0/1
[Btn][Px] Shutter - Stop
(End Pressing) Lower = Stop-Down; Upper = Stop-
Up
1 Bit
C T - - -
DPT_Trigger
0/1
[Btn][Px] Shutter - Stop
(End Pressing) Lower = Stop-Up; Upper = Stop-
Down
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Short Press
Lower = 0; Upper = 1
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Short Press
Lower = 1; Upper = 0
73, 79, 85, 91
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Px] Light - Dimming
(Long Press) Left = Darker; Right = Brighter
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Px] Light - Dimming
(Long Press) Left = Brighter; Right = Darker
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Px] Light - Dimming
(Long Press) Lower = Darker; Upper = Brighter
4 Bit
I
C T - W -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Btn][Px] Light - Dimming
(Long Press) Lower = Brighter; Upper = Darker
