Zennio FLAT - Page 50

Flat & Flat 55
http://www.zennio.com Technical Support: http://support.zennio.com
50
74, 80, 86, 92
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Long Press
Left = 0; Right = 1
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Long Press
Left = 1; Right = 0
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Long Press) Left = Down; Right = Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Start Pressing) Left = Down; Right = Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Long Press) Left = Up; Right = Down
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Start Pressing) Left = Up; Right = Down
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Long Press) Lower = Down; Upper = Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Long Press) Lower = Up; Upper = Down
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Start Pressing) Lower = Down; Upper = Up
1 Bit
C T - - -
DPT_UpDown
0/1
[Btn][Px] Shutter - Move
(Start Pressing) Lower = Up; Upper = Down
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Long Press
Lower = 0; Upper = 1
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] Two objects - Long Press
Lower = 1; Upper = 0
75, 81, 87, 93
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] LED On/Off
0 = On; 1 = Off
1 Bit
I
C T - W -
DPT_Switch
0/1
[Btn][Px] LED On/Off
0 = Off; 1 = On
76, 82, 88, 94
1 Byte
I
C T - W -
DPT_Scaling
0% - 100%
[Btn][Px] Light - Dimming (Status)
0 - 100 %
96
1 Byte
I
C - - W -
DPT_SceneControl
0-63; 128-191
[Thermostat] Scene Input
Scene Value
97
2 Bytes
I
C - - W -
DPT_Value_Temp
-273.00 - 670760.00
[Tx] Temperature Source 1
External Sensor Temperature
98
2 Bytes
I
C - - W -
DPT_Value_Temp
-273.00 - 670760.00
[Tx] Temperature Source 2
External Sensor Temperature
99
2 Bytes
O
C T R - -
DPT_Value_Temp
-273.00 - 670760.00
[Tx] Effective Temperature
Effective Control Temperature
100
1 Byte
I
C - - W -
DPT_HVACMode
1=Comfort
2=Standby
3=Economy
4=Building Protection
[Tx] Special Mode
1-Byte HVAC Mode
101
1 Bit
I
C - - W -
DPT_Ack
0/1
[Tx] Special Mode: Comfort
0 = Nothing; 1 = Trigger
1 Bit
I
C - - W -
DPT_Switch
0/1
[Tx] Special Mode: Comfort
0 = Off; 1 = On
102
1 Bit
I
C - - W -
DPT_Ack
0/1
[Tx] Special Mode: Standby
0 = Nothing; 1 = Trigger
1 Bit
I
C - - W -
DPT_Switch
0/1
[Tx] Special Mode: Standby
0 = Off; 1 = On
103
1 Bit
I
C - - W -
DPT_Ack
0/1
[Tx] Special Mode: Economy
0 = Nothing; 1 = Trigger
1 Bit
I
C - - W -
DPT_Switch
0/1
[Tx] Special Mode: Economy
0 = Off; 1 = On
104
1 Bit
I
C - - W -
DPT_Ack
0/1
[Tx] Special Mode: Protection
0 = Nothing; 1 = Trigger
1 Bit
I
C - - W -
DPT_Switch
0/1
[Tx] Special Mode: Protection
0 = Off; 1 = On
105
1 Bit
I
C - - W -
DPT_Window_Door
0/1
[Tx] Window Status (Input)
0 = Closed; 1 = Open
106
1 Bit
I
C - - W -
DPT_Ack
0/1
[Tx] Comfort Prolongation
0 = Nothing; 1 = Timed Comfort
107
1 Byte
O
C T R - -
DPT_HVACMode
1=Comfort
2=Standby
3=Economy
4=Building Protection
[Tx] Special Mode Status
1-Byte HVAC Mode
108
2 Bytes
I
C - - W -
DPT_Value_Temp
-273.00 - 670760.00
[Tx] Setpoint
Thermostat Setpoint Input
2 Bytes
I
C - - W -
DPT_Value_Temp
-273.00 - 670760.00
[Tx] Basic Setpoint
Reference Setpoint
109
1 Bit
I
C - - W -
DPT_Step
0/1
[Tx] Setpoint Step
0 = Decrease Setpoint; 1 = Increase Setpoint
