7.4 ADDRESS - ZONE TABLE
On the Simplicity 64 and 126, each available address corresponds to a zone, with 1-16 being in zone 1 by default, 17-32
being in zone 2 by default, 33-48 in zone 3 by default etc. On the Simplicity 252, by default addresses 1-32 are in zone 1,
33-64 in zone 2 etc.
The following table shows the dip switch settings for each address, and the DEFAULT zone that address will be in.
Note that if the zone boundaries on Simplicity 252 are changed, the affected addresses will now be in a different
