SIMPLICITY PLUS INSTALLATION MANUAL
Approved Document No: GLT.MAN-107 PAGE 43
Issue 3.16 Author: NRPJ Date: 21/09/2017
20. STANDBY BATTERY REQUIREMENTS
The Following Table shows the Quiescent, Fault & alarm currents of the main parts of a Simplicity Fire Alarm System
.
DEVICE PRODUCT CODE
I
Q
(MA)
I
FLT
(MA)
I
ALM
(MA)
MAX
PER
LOOP
MAX
PER
SYSTEM
SIMPLICITY PLUS 64 Fire Alarm Panel SP-64 90 105 115 N/A 1
SIMPLICITY PLUS 126 Fire Alarm Panel SP-126 90 105 115 N/A 1
SIMPLICITY PLUS 252 Fire Alarm Panel SP-252 115 120 130 N/A 1
Premier Addressable REPEATER PANEL REP-AD 200 220 220 N/A 4*
Fyreye MKII Addressable Optical Smoke Detector MKII-AOP 0.5 N/A 5.0 126 252
Fyreye MKII Addressable Heat Detector MKII-AHR 0.5
126 252
Zeta Addressable Call Point (EN54) ZT-CP3/AD 0.45 N/a 2.3 126 252
Zeta Weatherproof Addressable Call Point ZT-CP3/AD/WP 0.45 N/a 2.3 126 252
Zeta Addressable Input Module with SCI ZAI-MI 1.0 1.25 3.6 32 64
Zeta Addressable Input/ Output Module with SCI ZAIO-MI 1.0 1.25 2.0 16 32
Zeta Addressable Input/ Output Module with SCI –
mains switching
ZAIO-MI /230 0.9 2.8 19 10 20
Zeta Sounder Control Module ZASC-MI 0.6 0.6 0.8 16 32
Zone Monitor Unit ZAZM-MI 3.5 12.6 13.2 10 20
Fyreye Addressable Beam Detector (5-50m) ZT-BEAM + SMM/B 5 7 9 16 32
Sandwich Sounder Base MKII-SSB 0.6 N/a 7.5 32 64
Zeta Addressable Maxitone Sounder MKII/AMT 0.6 N/a 7.0 32 64
Zeta Addressable Maxitone Sounder flasher MKII/AMTF 0.6 N/a 10.6 24 48
Zeta Addressable Xtratone Sounder MKII/AXT 0.6 N/a 7.5 32 64
Zeta Addressable Maxitone Sounder flasher MKII/AXTF 0.6 N/a 7.5 24 48
Zeta Addressable Remote LED Indicator MKII-ARL/W(C) 0.45 N/a 2.1 32 64
Zeta Conventional wire Remote LED MKII-RL/W(C) 0 N/a 10 32 64
Conventional Sounders (via a sounder Control Circuit)
Zeta Conventional Maxitone Sounder ZMT/8 0 N/a 15 N/a N/a
Zeta Conventional Miditone Sounder ZMD/8 0 N/a 15 N/a N/a
Zeta Conventional Securetone Sounder ZST/8 0 N/a 15 N/a N/a
Zeta Conventional Megatone Sounder ZIDC 0 N/a 200 N/a N/a
Zeta Conventional Flasher ZFL2RR 0 N/a 90 N/a N/a
Zeta Conventional Sounder Flasher ZLT/8RR 0 N/a 110 N/a N/a
Zeta Conventional 6” Bells ZTB6B/24 0 N/a 25 N/a N/a
Zeta Conventional 8” Bells ZTB8B 0 N/a 35 N/a N/a
Conventional Detectors (via a Zone Monitor)
Fyreye MKII Conventional Optical Detector MKII-OP 0.06 N/a 25 N/a N/a
Fyreye MKII Conventional Heat Detector (A2R) MKII-HR 0.04 N/a 25 N/a N/a
Fyreye MKII Conventional Heat Detector (A2S) MKII-HF 0.04 N/a 25 N/a N/a
Fyreye MKII Conventional Opto-Heat Detector MKII-Oh 0.06 N/a 25 N/a N/a
GSM COMMUNICATOR GSM-COM 200 500 500 N/A 1
TCP-IP COMMUNICATOR TCP-IP 80 80 80 N/A 1
* The Simplicity can only power 1 repeater. Any subsequent ones will need a separate power supply.
