SIMPLICITY PLUS INSTALLATION MANUAL
Approved Document No: GLT.MAN-107 PAGE 47
Issue 3.16 Author: NRPJ Date: 21/09/2017
22. SPECIFICATIONS
22.1 ENCLOSURE SPECIFICATIONS
DESCRIPTION VALUE
ENCLOSURE SIZE 375 x 335 x 125 mm
TOP CABLE ENTRIES 12 x 19mm DIA GROMMETED ENTRIES
BOTTOM CABLE ENTRIES 2 x 19mm DIA GROMMETED ENTRIES
REAR CABLE ENTRIES 2 REMOVABLE CABLE ENTRIES, 60 x 20mm
22.2 ELECTRICAL SPECIFICATIONS
ELECTRICAL DESCRIPTION VALUE
MAINS VOLTAGE 230V AC +10% / -15% @ 50/60 Hz
BATTERY VOLTAGE 24V DC (2 X 12V SLA BATTERY)
SYSTEM VOLTAGE 28V DC NOMINAL (18 – 32 V)
SYSTEM VOLTAGE RIPPLE 1V PK-PK MAX
CHARGER SIZE 750mA
LOOP VOLTAGE 28V DC NOMINAL (+9 volt data)
SOUNDER ALARM OUTPUTS LOOP POWERED SOUNDERS ONLY
AUXILIARY FAULT OUTPUT 1 x FAULT RELAY SELV@1A (NORM. ENERG)
AUXILIARY FIRE OUTPUT 1 x FIRE RELAY SELV@1A
NUMBER OF LOOPS SIMPLICITY PLUS 64 - 1 LOOP
SIMPLICITY PLUS 126 - 1 LOOP
SIMPLICITY PLUS 252 - 2 LOOPS
MAXIMUM NUMBER OF ZONES SIMPLICITY PLUS 64 - 4 ZONES
SIMPLICITY PLUS 126 - 8 ZONES
SIMPLICITY PLUS 252 - 8 ZONES
MAXIMUM LOOP CAPACITY SIMPLICITY PLUS 64 – 64 Devices
SIMPLICITY PLUS 126 - 126 Devices
SIMPLICITY PLUS 252 - 126 Devices
MAXIMUM ZONE CAPACITY RECOMMENDED MAX - 32 DEVICES PER ZONE
MAXIMUM LOOP RESISTANCE 25 ohms
MAXIMUM LOOP CAPACITANCE 0.3μF
MAXIMUM VOLTAGE PICKUP ALLOWED 50mV
REMOTE SOUNDER ACTIVATION VIA N/O CONTACTS
CHARGER VOLTAGE
27.6V @ 22-24
o
C (NO BATTERY CONNECTED)
LOOP SHORT CIRCUIT PROTECTION 750mA
BATTERY DEEP DISCHARGE PROTECTION Batteries less than 19.7V
TOTAL PSU OUTPUT 2.5 Amp
