ZKTeco L5000 User Manual

Fingerprint Lock User Manual V1.0
26
Enroll FPCard
00003-0
Place Finger…
ESC
Enroll FPCard
00003-0
Second Press
ESC
Enroll FPCard
00003-0
Third Press
ESC
Enroll FPCard
00003: 1
Show the card
Enroll FPCard
00003: 1
Write succ
2) Press ▲/▼ to select an ID and then press OK to
confirm your selection and proceed to the next step.
Place one of your fingers on the fingerprint sensor.
3) Place the same finger on the fingerprint sensor
again.
4) Place the same finger on the fingerprint sensor
for the third time.
The interface as shown in the figure on the left is
displayed:
5) Swipe your card through the card reader until the
interface as shown in the figure on the left is
displayed.
Now the FP card is enrolled successfully.
2. Verify an enrolled FP card
Note: Please set the “Card Only” option to No. If you set it to Yes, the fingerprint
lock will only verify users’ PIN cards.

ZKTeco L5000 Specifications

General

Brand	ZKTeco
Model	L5000
Category	Door locks
Language	English
