1.3 Installation Requirements
Precautions:
1. The fingerprint lock is applicable to doors of 35–50 mm in thickness. Be sure to
list your special requirements or remarks for fingerprint locks to be installed on
doors in excess of 50 mm in thickness before placing an order.
2. The gap between the lock body and the box keep cannot exceed 4 mm;
otherwise, you need to adopt a liner plate to ensure the gap between them is not
more than 4 mm, as shown in the following figure:
≦4mm
3. Please make sure of the door opening directions and lock body. Assume you are
standing outside and facing a door and then there are four door opening
directions: Left inward, left outward, right inward and right outward. Left
inward/outward means the door swings inward/outward with hinges on the left;
right inward/outward means the door swings inward/outward with hinges on
the right, as shown in the following figure:
