2.2 I Hydraulic connecons
• A by-pass must be installed to make it easier to work on the appliance.
• The device will be connected to the pool's ltraon circuit with a Ø63 or Ø75 PVC pipe (depending on the model) using
the supplied connectors, aer the lter and before the water treatment. We strongly recommend the installaon of a
siphon if the water treatment system inlet is located less than 25 cm below the heat pump water outlet.
• Respect the direcon of hydraulic connecon.
• As a prevenve measure, we recommend that a non-return valve is added to prevent chemicals from reaching the
pump if the hydraulic circuit stops.
1.5 m *
1.5 m *
1.5 m *
1 m*
2 m*
: water inlet valve
: by-pass valve
: water outlet valve
: water inlet connector
(PVC-U union)
: water outlet connector
(PVC-U union)
(* minimum distance
Connecon to a standard ltraon circuit
Informaon: condensate drainage
Cauon, several litres of water can be drained from your appliance each day, which is related to the
condensaon of moisture contained in the air. We strongly recommend connecng the drain to a suitable
water drainage system. The installaon of a siphon is recommended inside the appliance to avoid stagnant
water.
