Zodiac Z950 - Specifications; Installation; Use; Maintenance

5
Tip: to make it easier to contact your retailer
• Write down your retailer's contact details to help you nd them more easily and ll in the "product"
informaon on the back of the manual; your retailer will ask you for this informaon.
• Before handling the appliance, it is vital that you read this installaon and user manual, as
well as the "Warranes" booklet delivered with the appliance. Failure to do so may result in
material damage or serious or fatal injury and will void the warranty.
• Keep and pass on these documents for later viewing throughout the appliance's service life.
• The distribuon or modicaon of this document in any way is prohibited, without prior
authorisaon from Zodiac®.
• Zodiac® is constantly developing its products to improve their quality. The informaon
contained herein may therefore be modied without noce.
CONTENTS
❶ Specicaons 6
1.1 I Descripon 6
1.2 I Technical specicaons 7
1.3 I Dimensions and marking 8
❷ Installaon 9
2.1 I Selecng the locaon 9
2.2 I Hydraulic connecons 10
2.3 I Electrical connecons 11
❸ Use 13
3.1 I Operang principle 13
3.2 I User interface presentaon 13
3.3 I Operaon 16
3.4 I User funcons 17
❹ Maintenance 20
4.1 I Winterising 20
4.2 I Maintenance 21
❺ Troubleshoong 22
5.1 I Appliance behaviour 22
5.2 I Error code display 23
5.3 I Advanced seng parameters (accessible by a qualied technician) 25
5.4 I Advanced operang principles 28
5.5 I Wiring diagrams 30
v v
EN
