12
2.3.2 "Heang priority" opon
• Before any work inside the appliance, you must cut the appliance’s electricity supply as there
is a risk of electric shock which may cause material damage, serious injury or even death.
• Use cables with a secon of at least 2x0.75 mm², RO2V type and with a diameter between 8
and 13 mm.
This funcon allows the appliance to start or maintain ltraon in order to detect the water temperature and thus acvate
the ltraon + heang unit to maintain a constant water temperature. The lter pump is thus said to be slaved to the
heang system. Filtraon is kept in operaon or acvated if the pool temperature falls below the desired temperature
(see § “5.3 I Advanced seng parameters (accessible by a qualied technician)”).
The start-up of the pool's ltraon pump also starts up the compressor. When the compressor stops, this also stops the
ltraon pump.
The me between the compressor start-up and the pump start-up is congurable, just like the me between
the compressor stopping and the pump stopping.
• Connect as shown below.
Power for the lter pump
Two possible
connecons for the
lter pump :
Two-pole
Three-pole
Heat pump
Filtraon mer
