3.4.5 Sensor temperature reading
• Press to display the temperature sensor values and the compressor consumpon (the three values correspond
to each of the compressor phases).
• Press or to display the dierent values (which are detailed in the table below) .
T1 Water inlet temperature
T2 Evaporator 1 sensor (defrost sensor)
T3 Discharge sensor 1
T4 Sucon sensor 1
T5 Evaporator 2 sensor (defrost sensor)
T6 Discharge sensor 2
T7 Sucon sensor 2
T8 Ambient temperature:
T9 Water outlet temperature
T10 Circuit 1 valve posion
T11 Circuit 2 valve posion
T12 NA
T13 NA
T14 NA
T15 NA
T16 Phase 1 current Compressor 1
T17 Phase 2 current Compressor 1
T18 Phase 3 current Compressor 1
T19 Phase 1 current Compressor 2
T20 Phase 2 current Compressor 2
T21 Phase 3 current Compressor 2
• The values related to compressor consumpon can uctuate depending on the water and outside air
temperatures. The consumpon values of the compressor phases do not necessarily have to match.
