Zoom B2FOUR User Manual

❻
Expression pedal (ZOOM FP02M)
A pedal can be used to control effects.
❼
PA mixer, etc.
Use to enabled/disable ground connection for the BALANCED OUTPUT jack.
This connects the ground pin to the ground.
This disconnects the ground pin from the ground.
This is useful if noise is caused by a ground loop.
❽
Computer (Mac/Windows), smartphone or tablet
Connect with a USB cable (Type-C).
The B2 FOUR can be used as an audio interface and with Handy Guitar Lab.
❾
Headphones
HINT:
The Handy Guitar Lab for B2 FOUR app (iOS/iPadOS) can be used to manage patch memories and to edit
and add effects. Handy Guitar Lab for B2 FOUR can be downloaded from the App Store.
19

Zoom B2FOUR Specifications

General

Type	Bass Multi-Effects Processor
Simultaneous Effects	5
MIDI I/O	No
USB	1 x USB-C
Looper	Yes
Inputs	1 x 1/4" (instrument)
Outputs	1 x 1/4" (main out)
Power Source	4 x AA batteries
Headphones	1 x 1/8"
