ENCODER 1 PCB : PCB-0156A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 Rotary Encoder RE160-40E3-15A-24P-017 16mm Vertical type with Nut/Washer SW30 SW31 SW32 SW33 SW34 5
REB161PVB15FHINA1-2-24PCE 16mm Vertical type with Nut/Washer SW30 SW31 SW32 SW33 SW34 0
2 CONNECTOR 2.0T-1-11A 2.0mm pitch 11pin CNB_ENC1 0
3 Harness ZH-0074-25: 2mm pitch 14pin L=250mm
to MAIN PCB and ENCODER2 PCB(Two-way Harness)
AWG22 Board In (Encoder 1 PCB only)
CNA_ENC-CNB_ENC1/CNB_ENC2 1
4 PCB PCB-0156A FR-1 130 x 34mm (104) 1
ENCODER 2 PCB : PCB-0157A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 Rotary Encoder RE160-40E3-15A-24P-017 16mm Vertical type with Nut/Washer SW35 1
REB161PVB15FHINA1-2-24PCE 16mm Vertical type with Nut/Washer SW35 0
2 CONNECTOR 2.0T-1-3AW 2.0mm pitch 3pin Side type CNB_ENC2 1
3 PCB PCB-0157A Part of ENCODER 1 PCB (105) 1
FOOT SW 1 PCB : PCB-0158
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 IC NJM2100M-TE1 SOP-8pin IC500 IC602 2
2 Digital Tr BCR553 SC59
DT500 DT501 DT502 DT503 DT504
DT505 DT506 DT507
8
DTB123EKT146 SC59
DT500 DT501 DT502 DT503 DT504
DT505 DT506 DT507
0
3 Transistor BC817-40 SC59 Q1 Q600 2
2SC1623 SC59 Q1 Q600 0
BC817-40LT1G SC59 Q1 Q600 0
4 Diode 1SS133T-77 Pitch=7.5mm
D500 D501 D502 D503 D505
D506 D507
7
5 LED KSNR-312N-30 Radial LED27 LED29 2
6 LED 3A9RYGX-C LED12 LED613 2
SPR-39MVW LED12 LED613 0
7 Capacitor(Unmounting) open-c D=4.0mm H=7.0-11.5mm Pitch=5mm C625 C627 0
8 Capacitor(Unmounting) 10u/16V(open) D=4.0mm H=7.0-11.5mm Pitch=5mm C501 C621 C624 C626 0
9 Capacitor(Unmounting) 100u/16V(open) D=4.0mm H=7.0-11.5mm Pitch=5mm C500 0
10 Chip Capacitor 0.1u-Z F (25V) 1608(0603) C502 C623 2
11 Chip Capacitor(Unmounting) open-c 1608(0603) C503 C504 C620 C622 0
12 Resistor 0 Pitch=7.5mm R637 1
13 Resister 33-J 1/8W Pitch=7.5mm R535 R623 2
14 Resister 51-J 1/8W Pitch=7.5mm R518 R519 2
15 Resister 75-J 1/8W Pitch=7.5mm R546 R624 2
16 Resister 220-J 1/8W Pitch=7.5mm
R547 R548 R549 R550 R551
R552 R553 R554
8
17 Resister 330-J 1/8W Pitch=7.5mm R555 R628 R633 3
18 Resister 10k-J 1/8W Pitch=7.5mm
R509 R556 R557 R626 R629
R632
6
19 Resister 22k-J 1/8W Pitch=7.5mm R635 1
20 Resister 47k-J 1/8W Pitch=7.5mm R508 R560 R627 R634 4
21 Resister 110k-J 1/8W Pitch=7.5mm R558 R559 R630 R631 4
22 Resister(Unmounting) open-r Pitch=7.5mm R636 R638 R639 0
23 Trimmer potentiometer TC-655MH501 500-B VR500 VR600 VR601 3
24 TACT SW 1104RTA-2 SW22 SW24 SW26 SW628 4
25 CONNECTOR 2.0T-1-10A 2.0mm pitch 10pin CNA_FT11 CNA_FT17 2
25 CONNECTOR 2.0T-1-12A 2.0mm pitch 12pin CNA_FT12 1
26 FPC CONNECTOR 11311124-12420000 1mm pitch 24pin FFC side type CNB_FT1M 1
52807-2410 1mm pitch 24pin FFC side type CNB_FT1M 0
27 CONNECTOR 2.0T-1-2A 2.0mm pitch 2pin CNB_SWL CNB_SWR 2
28 CONNECTOR 2.0T-1-3A 2.0mm pitch 3pin CNB_PHL CNB_PHR 2
29 CONNECTOR 2.0T-1-4A 2.0mm pitch 4pin CNB_PHZ 1
30 Harness ZH-0074-7: 2mm pitch 3pin L=320mm to MAIN PCB Flat Cable , Board In CNA_PDLL-CNB_PDLL 1
31 Harness ZH-0074-10: 2mm pitch 5pin L=340mm to MAIN PCB Flat Cable , Board In CNA_PDLR-CNB_PDLR 1
32 Harness ZH-0074-20: 2mm pitch 9pin L=80mm to FOOT2 SW PCB Flat Cable , Board In CNA_FT21-CNB_FT21 1
33 FPC Cable ZH-0074-26: 1mm pitch 24pin L=120mm to MAIN PCB 1mm pitch FFC Cable CNA_FT1M-CNB_FT1M 1
34 Jumper wire Pitch=7.65mm
JP001 JP002 JP003 JP004 JP005
JP006 JP007 JP008 JP009 JP010
JP011 JP012 JP013 JP014 JP015
JP016 JP017 JP018 JP019 JP020
JP021 JP022 JP023 JP024 JP025
JP026 JP027 JP601
28
35 Jumper wire Pitch=10mm
JP100 JP101 JP102 JP103 JP104
JP105
6
36 Jumper wire Pitch=15mm JP300 JP301 JP302 JP303 JP304 5
37 Jumper wire Pitch=25mm JP400 1
38 PCB PCB-0158A FR-1 379 x 44mm (81) 1
FOOT SW 2 PCB : PCB-0159
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 LED KSNR-312N-30 Radial LED16 LED18 LED20 LED22 LED624 5
2 Resister 51-J 1/8W Pitch=7.5mm R520 R521 R522 R523 R625 5
3 TACT SW 1104RTA-2 SW21 SW23 SW25 SW27 SW629 5
4 CONNECTOR 2.0T-1-9AW 2.0mm pitch 9pin Side type CNB_FT21 1
5 Harness ZH-0074-18: 2mm pitch 8pin L=220mm to MAIN PCB Flat Cable , Board In CNA_FT2M-CNB_FT2M 1
6 PCB PCB-0159A Part of FOOT SW 1 PCB (83) 1
PEDAL SW-L PCB : PCB-0160
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 TACT SW 1104RTA-2 SW600 1
2 Harness ZH-0074-3: 2mm pitch 2pin L=200mm to FOOT SW 1PCB Flat Cable, Board In CNA_SWL-CNB_SWL 1
3 PCB PCB-0160A FR-1 52 x 30mm (50) 1
PEDAL SW-R PCB : PCB-0161
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 TACT SW 1104RTA-2 SW500 1
2 Harness ZH-0074-3: 2mm pitch 2pin L=200mm to FOOT SW 1 PCB Flat Cable, Board In CNA_SWR-CNB_SWR 1
3 PCB PCB-0161A Part of PEDAL SW-L PCB (80) 1
PHOTO L PCB : PCB-0162
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 Photo Reflector NJL5167KB DIP-4pin NJL5167K IC604 1
2 Harness ZH-0074-6: 2mm pitch 3pin L=150mm to FOOT SW 1 PCB Flat Cable, Board In CNA_PHL-CNB_PHL 1
3 PCB PCB-0162A Part of PEDAL SW-L PCB (39) 1
PHOTO-R PCB : PCB-0163
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 Photo Reflector NJL5167KB DIP-4pin NJL5167K IC501 1
2 Harness ZH-0074-6: 2mm pitch 3pin L=150mm to FOOT SW 1 PCB Flat Cable, Board In CNA_PHR-CNB_PHR 1
3 PCB PCB-0163A Part of PEDAL SW-L PCB (103) 1
PHOTO Z PCB : PCB-0164
A
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 Photo Reflector GP2S40J0000F DIP-4pin IC603 1
2 Harness ZH-0074-9: 2mm pitch 4pin L=250mm to FOOT SW 1 PCB Flat Cable, Direct mounting CNA_PHZ-CNB_PHZ 1
3 Jumper wire Pitch=7.65mm JP600 1
4 PCB PCB-0164A Part of FOOT SW 1 PCB (93) 1
- 46 -
