66 Chip Resistor 2.4k-J 1608(0603) R224 R257 R731 R742 4
67 Chip Resistor 3.9k-J 1608(0603) R283 R293 2
68 Chip Resistor 4.7k-J 1608(0603)
R229 R230 R321 R322 R323
R324 R276 R277 R316 R320
R729 R756 R763
13
69 Chip Resistor 5.1k-J 1608(0603) R714 1
70 Chip Resistor 7.5k-J 1608(0603)
R333 R334 R335 R336 R337
R338 R718 R760
8
71 Chip Resistor 8.2k-J 1608(0603) R210 R232 R712 R724 4
72 Chip Resistor 10k-J 1608(0603)
R202 R225 R227 R253 R258
R262 R269 R270 R271 R272
R275 R296 R297 R298 R300
R301 R302 R303 R704 R706
R726 R728
22
73 Chip Resistor 12k-J 1608(0603)
R282 R284 R292 R294 R325
R326
6
74 Chip Resistor 13k-J 1608(0603) R219 R220 R247 R248 4
75 Chip Resistor 15k-J 1608(0603)
R204 R206 R212 R213 R214
R221 R238 R239 R240 R249
R743 R761
12
76 Chip Resistor 20k-J 1608(0603) R328 R330 2
77 Chip Resistor 22k-J 1608(0603)
R209 R231 R278 R279 R286
R287 R305 R306 R353 R752
R762
11
78 Chip Resistor 30k-J 1608(0603)
R233 R235 R701 R741 R744
R745
6
79 Chip Resistor 39k-J 1608(0603) R355 R356 2
79 Chip Resistor 43k-J 1608(0603) R722 R721 2
80 Chip Resistor 47k-J 1608(0603)
R211 R223 R228 R234 R252
R254 R265 R299 R304 R311
R312 R313 R314 R713 R723
R734 R747 R757 R740
19
81 Chip Resistor 100k-J 1608(0603)
R327 R329 R347 R348 R255
R256
6
82 Chip Resistor 180k-J 1608(0603) R700 1
83 Chip Resistor 220k-J 1608(0603) R331 R332 R345 R346 R705 5
84 Chip Resistor 1M-J 1608(0603) R203 R290 R730 R755 4
85 Chip Resistor(Unmounting) open-r 1608(0603)
R200 R205 R208 R266 R267
R308 R310 R315 R317 R349
R350 R351 R354 R357 R709
R710 R711 R716 R720 R725
R738 R751 R758 R735 R750
R754 R765 R766 R768
0
86 Volume F-095V5G A10K L15FC*7 (M) 10k-A dual horizontal VR200 1
87 Trimmer potentiometer TC-655MH103 10k-B VR203 VR204 VR702 VR700 4
RH0411C14J 10k-B VR203 VR204 VR702 0
88 Trimmer potentiometer(Unmounting) open-vr VR704 0
89 Slide SW SK22H09-G9 SW200 SW700 2
MCS-222N-1010 SW200 SW700 0
HSW2022-010020 Length of lever=9mm SW200 SW700 0
90 Stereo Mini Jack SJ-3507-5P with nut J201 1
91 Phone Jack SJ6335 J200 J202 J203 J701 4
92 Stereo Phone Jack SJ6336 J204 J700 2
93 USB Connector 57112201-2110000 J205 1
YKF45-0023 J205 0
94 Connector 3.96T-3-3A 3.96mm pitch 3pin CN401A 1
95 Connector 2.0T-1-3A 2mm pitch 3pin CNA_ACC_SOLID 1
96 Connector 2.0T-1-6A 2mm pitch 6pin
CN8B
CNA
_
TUBE
CNA
-
TONE
CNA ACC TUBE
4
97 Connector 2.0T-1-7A 2mm pitch 7pin CN7B 1
98 Connector 2.0T-1-8A 2mm pitch 8pin CNA_ENG CNA_ACC 2
99 Connector 2.0T-1-10A 2mm pitch 10pin CN603B 1
100 Harness ZH-0074-2: 3.96mm pitch 2pin L=380mm to MAIN PCB AWG18 , board in CN402A-CN402B 1
101 Harness ZH-0074-14: 2mm pitch 6pin L=220mm to MAIN PCB Flat Cable CN8A-CN8B 1
102 Harness ZH-0074-15: 2mm pitch 7pin L=200mm to MAIN PCB Flat Cable CN7B-CN7A 1
103 Harness ZH-0074-27: 2mm pitch 10pin L=185mm to MAIN PCB Flat Cable CN603A-CN603B 1
104 Jumper wire Pitch=5mm JP400 JP401 JP402 3
105 PCB PCB-0165 FR-4 2layer 284 x 100mm (73) 1
TUBE PCB : PCB-0166
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 TUBE 12AX7 MT9 Q210 1
12AX7WA MT9 Q210 0
2 TUBE SOCKET GZC9-1B PCB mounting Q210 1
3 Connector 2.0T-1-8A 2mm pitch 8pin CNB_ENG 1
4 Harness ZH-0074-19: 2mm pitch 8pin L=60mm to Analog PCB Flat Cable CNA_ENG-CNB-ENG 1
5 PCB PCB-0166 Part of ANALOG PCB (79) 1
ACC TUBE PCB : PCB-0167
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 TUBE 12AX7 MT9 Q702 1
12AX7WA MT9 Q702 0
2 TUBE SOCKET GZC9-1B PCB mounting for Q702 Q702 1
3 Connector 2.0T-1-8A 2mm pitch 8pin CNB_ACC 1
4 Harness ZH-0074-16: 2mm pitch 8pin L=60mm to Analog PCB Flat Cable CNA_ACC-CNB-ACC 1
5 PCB PCB-0167 Part of ANALOG PCB (63) 1
