Appendix A
Reference Design Protocol Specification
Commands
Table A-1 lists the commands used in the evaluation tool design.
Table A-1: Command List
Command Arguments Return Purpose/Comments
Basic Commands
RFdcVersion None Version Number(s) RFdc API Version, for example,
"v3_1"
Version None Version Number(s) Protocol Version, for example,
"v1_0"
TermMode mode None Switch between UI mode
(mode=0) and Interactive mode
(mode=1). Interactive mode
prints more status info to the
terminal, and should not be used
with the Evaluation Tool GUI.
GetLog None Logged Strings Uses metal_log to return any
error, warning, or informational
messages returned from the API
or command interface.
iic_write iic instance, slave
address, register offset,
size, data
Success/Fail Write number of bytes to IIC slave
iic_read iic instance, slave
address, size
Success/Fail Read number of bytes from IIC
slave
RFdc API Commands
SetMixerSettings Type, Tile, Block,
MixerSettings
None Where MixerSettings is 1:1 with
the API:
Freq, PhaseOffset, EventSource,
FineMixerMode,
CoarseMixerFreq, FineMixerScale
GetMixerSettings Type, Tile, Block Type, Tile, Block,
MixerSettings
Get mixer settings for the
requested type, tile, and block.
