Chapter 22 WLAN Station Status
LTE Series User’s Guide
234
CHAPTER 22
WLAN Station Status
22.1 WLAN Station Status Overview
Use this screen to view information and status of the wireless stations (wireless clients) that are currently
associated with the Zyxel Device. Being associated means that a wireless client (for example, your
computer with a wireless network card installed) has connected successfully to an AP (or wireless router)
using the same SSID, channel, and WiFi security settings.
Click System Monitor > WLAN Station Status to open the following screen.
Figure 172 System Monitor > WLAN Station Status
The following table describes the labels in this screen.
Table 98 System Monitor > WLAN Station Status
LABEL DESCRIPTION
# This is the index number of an associated wireless station.
MAC Address This field displays the MAC address of an associated wireless station.
Rate (Mbps) This field displays the transmission rate of WiFi traffic between an associated wireless station and
the Zyxel Device.
RSSI (dBm) The RSSI (Received Signal Strength Indicator) field shows the WiFi signal strength of the station’s
wireless connection.
The normal range is -30dBm to -79dBm. If the value drops below -80dBm, try moving the
associated wireless station closer to the Zyxel Device to get better signal strength.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
