ZyXEL Communications LTE5388-M804 User Manual

LTE Series User’s Guide
236
CHAPTER 23
VoIP Status
23.1 VoIP Status Screen
Click System Monitor > VoIP Status to open the following screen. You can view the VoIP registration,
current call status and phone numbers in this screen.
Figure 173 System Monitor > VoIP Status
The following table describes the labels in this screen.
Table 99 System Monitor > VoIP Status
LABEL DESCRIPTION
Poll Interval Enter the number of seconds the Device needs to wait before updating this screen and then
click Set Interval. Click Stop to have the Device stop updating this screen.
SIP Status
Account This column displays each SIP account in the Device.
Registration This field displays the current registration status of the SIP account. You can change this in the
Status screen. Registered - The SIP account is registered with a SIP server. Not Registered - The
last time the Device tried to register the SIP account with the SIP server, the attempt failed. The
Device automatically tries to register the SIP account when you turn on the Device or when
you activate it. Inactive - The SIP account is not active. You can activate it in VoIP > SIP > SIP
Account.

ZyXEL Communications LTE5388-M804 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
3G standards	HSPA+, HSUPA, WCDMA
UMTS bands supported	850, 900, 1800, 2100 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
MAC address table	64 entries
Security algorithms	WPA, WPA2
Supported network protocols	IPv4/IPv6
Product type	Tabletop router
Product color	Grey, White
LED indicators	LTE, Power, USB, WLAN
Power source type	DC
Power consumption (typical)	24 W
Certification	CE, WEEE, RoHS, HSF
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Package type	Box
Package depth	170 mm
Package width	247 mm
Package height	120 mm
Package weight	1600 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	100 mm
Height	205 mm
Weight	599 g
