Chapter 2 The Web Configurator
LTE Series User’s Guide
42
2.2.1.3 Dashboard
Use the menu items in the navigation panel on the right to open screens to configure the Zyxel Device’s
features.
Figure 33 Navigation Panel
2.2.2 Widget Icon
Click this icon ( ) in the lower left corner to arrange the screen order.
Log Setting Log Setting Use this screen to change your Zyxel Device’s log settings.
Firmware
Upgrade
Firmware
Upgrade
Use this screen to upload firmware to your Zyxel Device.
Backup/Restore Backup/Restore Use this screen to backup and restore your Zyxel Device’s configuration
(settings) or reset the factory default settings.
Reboot Reboot Use this screen to reboot the Zyxel Device without turning the power off.
Diagnostic Ping&Traceroute
&Nslookup
Use this screen to identify problems with the DSL connection. You can
use Ping, TraceRoute, or Nslookup to help you identify problems.
Table 11 Navigation Panel Summary (continued)
LINK TAB FUNCTION
