Chapter 31 Log Setting
LTE Series User’s Guide
262
Figure 189 Maintenance > Log Setting
The following table describes the fields in this screen.
Table 114 Maintenance > Log Setting
LABEL DESCRIPTION
Syslog Settings
Syslog Logging Click the switch (it will turn blue) to enable syslog logging.
Mode Select Remote to have the Zyxel Device send it to an external syslog server.
Select Local File to have the Zyxel Device save the log file on the Zyxel Device itself.
Select Local File and Remote to have the Zyxel Device save the log file on the Zyxel Device itself
and send it to an external syslog server.
Note: A warning appears upon selecting Remote or Local File and Remote.
Just click OK to continue.

Table of Contents

Other manuals for ZyXEL Communications LTE5388-M804

Questions and Answers:

ZyXEL Communications LTE5388-M804 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1733 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
4G standardLTE-TDD & LTE-FDD
3G standardsHSPA+, HSUPA, WCDMA
UMTS bands supported850, 900, 1800, 2100 MHz
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
MAC address table64 entries
Security algorithmsWPA, WPA2
Supported network protocolsIPv4/IPv6
Product typeTabletop router
Product colorGrey, White
LED indicatorsLTE, Power, USB, WLAN
Power source typeDC
Power consumption (typical)24 W
CertificationCE, WEEE, RoHS, HSF
Storage temperature (T-T)-30 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Cables includedLAN (RJ-45), Phone (RJ-11)
Package typeBox
Package depth170 mm
Package width247 mm
Package height120 mm
Package weight1600 g
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Width100 mm
Height205 mm
Weight599 g
