Chapter 4 Tutorials
LTE Series User’s Guide
55
This example shows you how to configure the SSIDs with the following parameters on your Zyxel Device.
1 Connect your computer to the LAN port of the Zyxel Device using an Ethernet cable.
2 The default IP address of the Zyxel Device is “192.168.1.1”. In this case, your computer must have an IP
address in the range between “192.168.1.2” and “192.168.1.254”.
3 Click Start > Run on your computer in Windows. Type “cmd” in the dialog box. Enter “ipconfig” to show
your computer’s IP address. If your computer’s IP address is not in the correct range then see Section 7.3
on page 104 for information on changing your computer’s IP address.
4 After you’ve set your computer’s IP address, open a web browser such as Internet Explorer and type
“http://192.168.1.1” as the web address in your web browser.
5 Use “admin” as the user name and “1234” (default) as the password and click Login.
6 Go to Configuration > Network Setting > Wireless > Guest/More AP. Click the Modify/Edit icon of the first
entry to configure wireless and security settings for SSID_Worker.
7 Configure the screen as follows. In this example, you enable Intra-BSS Traffic for SSID_Worker to allow
wireless clients in the same wireless network to communicate with each other. Click OK.
SSID SECURITY TYPE KEY
SSID_Worker WPA2-PSK
WPA Compatible
DoNotStealMyWirelessNetwork
SSID_VoIP WPA-PSK VoIPOnly12345678
SSID_Guest WPA-PSK keyexample123
