Configuration manual for 2N IP intercoms
•
•
•
•
•
•
•
The received message is displayed in the following format:
13:46:39] led(0,0,0,0,0,0,0,0,1,1,1,2,2)
13:46:39] buz(0,2,1,1,1)
13:46:42] led(0,0,0,0,0,0,0,0,1,1,1,1,1)
13:46:42] buz(0,1,0,0,0)
A part of the message (without the time value) is used as the definition string, whose length may
not exceed 255 characters, e.g.: led(0,0,0,0,0,0,0,0,1,1,1,1,1) or buz(0,2,1,1,1). Having evaluated a
match on the counterparty, the device responds with an adequate signaling. Any part of the
definition can be replaced with "*", which will be interpreted as an arbitrary message content
(e.g. it is possible to ensure that signaling will be activated upon any LED 0 light on the device
regardless of the other message parameters).
Clear Log – delete a Received messages record.
Integration with Other Systems
Enabled– enable connection with the Genetec Synergis external security system.
Synergis Server Address – Synergis server IP address or domain name.
Username– authentication user name.
Password – authentication password.
Format–set the card reading format for sending card IDs to Genetec Synergis.
Forward Code – set whether or not the set codes are to be resent. The codes may contain
up to 6 digits and their ends have to be confirmed with a key.
•
Note
Make sure that the Door / Unused parameter is set for the card reader and keypad
in Hardware / Extending modules to make the function work. The 2N IP intercom
confirms the card reading by a beep and the device responds with an appropriate
signaling after evaluation.
