4-6 CHAPTER 4: PERFORMING TROUBLESHOOTING AND DIAGNOSTIC TESTS
The diagnostic programs listed above come on the EtherDisk
diskette that accompanied the adapter.
4 From the main menu, select Echo Server Setup.
The program notifies you that your computer is now set up
as an echo server.
Starting the Group 3 Test
To run the Group 3 test on a Fast EtherLink PCI adapter,
follow these steps:
1 Start the Configuration and Diagnostic Program.
This program must be on the computer containing the
adapter you want to test.
2 Select Test Setup from the Test menu.
3 Select Group 3 from the Group Select box.
4 Enable the Group 3 test by highlighting the
<Enable Group> command button.
5 Highlight <OK> and press [Enter].
6 Go to the Run dialog box to start the tests.
Table 4-1 Adapter and Diagnostic Program Names (10 Mbps Adapter Only)
Diagnostic Program Name Adapter
3C503 EtherLink II
â
or II TP
EtherLink II/16 or II/16 TP
3C505 EtherLink Plus
â
3C507 EtherLink 16 or EtherLink 16 TP
3C5X9CFG EtherLink III family
3C523 EtherLink/MC
3C523TP EtherLink/MC TP
3C527 EtherLink/MC 32
