A
SPECIFICATIONS
This appendix lists the specifications for the Fast EtherLink PCI
adapter. It also contains pin assignments for the adapter’s
RJ-45 connector.
Adapter Card Specifications
Network Interface
Physical Dimensions
Environmental Operating Range
Power Requirements
10 Mbps
Ethernet
10BASE-T
Ethernet IEEE 802.3 industry standard
for a 10 Mbps baseband CSMA/CD
local area network
100 Mbps
Ethernet
100BASE-TX
Ethernet IEEE 802.3u standard for a
100 Mbps baseband CSMA/CD local
area network
Length: 17.46 cm (6.875 in.)
Height: 10.67 cm (4.2 in.)
Operating
temperature:
0˚ to 70˚ C (32˚ to 158˚ F)
Humidity: 10 to 90% noncondensing
Altitude: To 3,000 meters (9,840 ft)
Operating voltage: +5 V ± 5% @ 500 mA max
+12 V ± 5% @ 160 mA max
