3D Systems CubePro - Page 15

143D Systems, Inc.
23. Using a 2.5 mm hex head driver, loosen and remove both 2.5 mm
hex head screws securing the extruder PCB to the extruder. Carefully
remove the extruder PCB.
CAUTION: Be careful not to damage the print material sensor
(A).
24. Using steady pressure, carefully pull out the print material (A) from the
top of the extruder.
A
A
