ProJet
®
x60Pro Series User Guide ProJet x60Pro® Series Overview
3dscentral.3dsystems.com 7 All Rights Reserved
5/12/13
1.6 ProJet x60Pro Components
The main components of the ProJet x60Pro system are highlighted below.
1.6.1 System Exterior
Number ProJet 660Pro ProJet 860Pro
1 Printer Cover Printer Cover
2 Control Panel Control Panel
3 Printer Storage Compartment Printer Storage Compartment
4 Post-Processing Unit (PPU)
Cover
5 PPU Storage Compartment
6 Arm Holes
ProJet 660Pro
ProJet 860Pro
