3D Systems ProJet 660Pro - Carriage, Print Heads, and Pogo Pins; Front View

ProJet
®
x60Pro Series User Guide ProJet x60Pro® Series Overview
3dscentral.3dsystems.com 15 All Rights Reserved
5/12/13
1.10 Carriage, Print Heads, and Pogo Pins
1.10.1 Front View
Number Component
1 Print Head (removed)
2 Print Head Contacts
3 Pogo Pins (inside)
4 Septum
5 Print Head (installed)
6 Carriage Cover
