3Disc FireCR+ - Removing the Internal Cover

Service Manual FireCR
+
Computed Radiography Scanner
16 Parts Removal/Replacement | FireCR
+
Internal Cover
1. Remove Top Cover. (Pg. 14)
2. Remove the 6 screws on top of the Internal Cover (#2 Phillips). Note: Some scanners have 10
screws.
3. Disconnect the cassette lock cables from the cassette lock board and feed them through the
hole in the middle of the Internal Cover.
