3Disc FireCR+ - Replacing the Y-Axis Motor

Service Manual FireCR
+
Computed Radiography Scanner
FireCR
+
| Parts Removal/Replacement 25
10. Unplug wire connector from Main Board.
11. Process is the same for other aligner motor.
12. Reinstall in reverse order.
Y-Axis Motor
1. Remove Top Cover. (Pg. 14)
2. Remove Internal Cover. (Pg. 16)
3. Remove BLDC Bracket (2.5mm hex)
