Service Manual FireCR
+
Computed Radiography Scanner
34 Parts Removal/Replacement | FireCR
+
5. Loosen the 3 screws that hold down the Power Board (2.5mm hex).
6. Remove Power Board.
7. Connect all the cables (two switch cables, USB cable and power cable) onto a new Power Board
using the tweezers.
8. Replace screws.
