a. Loosen the adjustable nut on the bracket.
b. Adjust the panning angle [0~360°] of the camera.
c. Adjust the tilting angle [0~90°] of the camera.
d. Rotate 0~360° to adjust azimuth angle of the image.
e. Tighten the adjustable nut to complete the installation.
3-axis Adjustment
Adjustable
Nut
T Direction
R Direction
P Direction
