Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
71
Secure the Camera
VIEW ANGLE ADJUSTMENT
3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum camera rotation and placement.
PAN ADJUSTMENT
Steps:
TILT ADJUSTMENT
Steps:
