3xLogic VISIX S-Series Installation Manual

Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
18
Description of Overview (4)
Name/Label
Description
LAN（PoE）
10M/100M Self-adaptive Ethernet Port(PoE Supported)
AUDIO OUT/IN
Audio Out/In
CVBS,GND
Auxiliary video output
1A,1B
Alarm Out
D+,D-
RS-485 Interface
IN,GND
ALARM IN
DC12V
Power Supply Interface（12 VDC ）
NOTE: Press and hold RESET for 10s when the camera is powering on or rebooting to restore the default
settings, including the user name, password, IP address, port No., etc.
AVAILABLE MOUNTS
 D2 Ceiling Flush Mount (3xLOGIC Product #: VX-FM-D2)
 D2 Wall Mount (3xLOGIC Product #: VX-WM-D2)
 D2 Wall Mount w/ Junction Box (3xLOGIC Product #: VX-WMJ-D2)
 Universal Corner Mount (3xLOGIC Product #: VX-CM)
 Universal Pole Mount (3xLOGIC Product #: VX-POLE)
INSTALLATION — CEILING MOUNT
Steps:
Drill Template
BOTTOM
Hole
2
2
1
1
1
1
