Installation Manual v3.1 | VISIX S-Series Network Camera

12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC

Dome

Cover

Camera

Body

Screwdriver

Screw

Install the Dome Cover

INSTALLATION — WALL MOUNT

NOTE: Wall mounting bracket is not included in the package. You need to prepare a wall mounting bracket if

this mounting type is selected. The bracket shown in the following demonstration is only for reference.

Steps:

Install the Wall Mount Bracket

NOTE: Insert the expansion screws first if the camera is mounted to the cement wall, and you can use the

self-tapping screws directly if camera is mounted to the wooden wall.
