Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
24
INSTALL PREPARATION - MEMORY CARD INSTALLATION
Steps:
1. Rotate the camera body to completely expose the memory card slot.
2. Insert the memory card into the memory card slot, and push it in to mount the card.
Memory Card
Install the Memory Card
3. (Optional) To unmount the memory card, push on the card to eject.
INSTALLATION - CEILING MOUNTING
1. Attach the supplied drill template to the location where you want to install the camera.
2. Drill the screw holes and the cable hole according to the drill template as the figure below.
Drill Template
