4NSYS 4CH - 3 System Operation; Icon

DIGITAL VIDEO RECORDER MANUAL
DIGITAL VIDEO RECODER MANUAL
12
[1] AUDIO OUTPUT
[2] AUDIO INPUT
[3] VIDEO INPUT
[4] VIDEO OUTPUT (COMPOSITE)
[5] VGA OUTPUT
[6] ETHERNET PORT (RJ-45)
[7] USB PORT (USB Drive / Mouse)
[8] RS-485/ALARM/SENSOR
[9] POWER (ADAPTER)
3 — System Operation
[1] The icons on the live screen indicate the status.
Icon
