User Manual NUVOLAS
April 2023
File: User Manual_NUVOLAS_rev3.docx 19
4.12 Safety shutter / Aiming Beam
The NUVOLAS has an internal safety shutter. This shutter is opened mechanically by
inserting the fiber. Only if a fiber is properly plugged in, the laser can be switched into
READY mode by pressing the READY button.
The aiming beam is only visible when a fiber is plugged in and the laser is in the READY
mode. This aiming beam is a laser beam with very low power.
4.13 Manual Reset
If an error occurs, the system switches into STANDBY mode and an error message is
shown. A restart should fix the error due to the automatic recalibration. Please refer to
chapter 8.5.3 to identify the error messages.
If the error still occurs, this can only be remedied by trained personnel. Please contact
the service of A.R.C. Laser GmbH in this case.
4.14 Reset by Power Failure
If the device is disconnected from the power grid accidentally - e.g. due to a power failure
- it usually restarts automatically. The system recalibrates and deletes all unsaved
settings. If there is still an error, it can only be corrected by trained personnel. Please
contact A.R.C. Laser GmbH service department should this occur.
