User Manual NUVOLAS
April 2023
File: User Manual_NUVOLAS_rev3.docx 39
7 Technical Data
7.1 General
Model NUVOLAS Diode laser
Cooling Air internal
Weight 24 kg
Dimensions H 16.1 cm / W 47.8 cm / D 42.1 cm
Controlling Touch screen display
7.2 Laser-Data
Wavelength
Power
Tolerance
514 nm
0.5 8 Watt
± 20% of displayed power
According to IEC 60601-2-22
Wavelength
Pulse length
Pulse pause
Frequency
514 nm
20 ms 60 s /CW
20 ms 60 s /SP
0,008 Hz 25 Hz /SP
Aiming Beam 635 nm red < 1 mW, variable brightness
continuous wave (CW)
Power transmission Fiber 300 μm, 400 μm, 600 μm
with or without handpiece
7.3 Electrical Connection Data
Power supply connection values 100V 240V, 50Hz/60Hz, 6.3 A/ 3.15 A
7.4 Classification
Laser class Laser Beam 4
(Classification EN 60825-1)
Laser class Aiming Beam 2
(Classification EN 60825-1)
Electrical protection class I
(Classification IEC 60601-1)
Classification according to IIb, Rule 9
MDD/MDR
Certification CE 0123
