User Manual NUVOLAS
April 2023
File: User Manual_NUVOLAS_rev3.docx 27
6.1 Preparation
A power supply unit is integrated in the NUVOLAS, which needs to be connected to the
mains. This is the standard power supply. Input voltage ranges between 100 V and 230 V.
Only use the power supply distributed by A.R.C. Laser GmbH.
Please refer to the following steps when preparing the device to operation in order to
avoid unnecessary troubleshooting or even possible malfunctions.
• Is the laser connected to the power supply?
The power supply only has to be connected if the device is switched off.
• Has the door interlock connector for the external interlock been plugged in? – or, if
applicable: has the door interlock contact been connected to the laser?
• Is a fiber or probe still connected?
• Are the fibers and probes free of any damage?
• Is there a sufficient number of protective glasses ready to be used?
• Has the footswitch been plugged in?
We recommend placing the NUVOLAS on a dry and solid surface. Ensure a stable stand
for the laser system.
A T T E N T I O N
All warning lights outside the treatment rooms must be switched on as soon as the
laser starts to operate. The doors have to be marked accordingly, visible from outside
(with the warning signs).
