SubCompact Board GENE-9455
z Gross Weight 0.88 lb (0.4 kg)
z Operating Temperature 32˚F~ 140˚F (0˚C ~ 60˚C)
z Storage Temperature -40˚F~ 176˚F (-40˚C ~ 80˚C)
z Operating Humidity 0%~90% relative humidity,
non-condensing
Display Supports CRT/LCD simultaneous/dual view displays
z Chipset Intel
®
945GSE integrated
z Memory Shared system memory up to
224MB/ DVMT3.0
z LCD Interface Up to 18-bit dual-channel LVDS
z Resolution Up to 2048 x 1536 @ 32bpp for
CRT; Up to 1600 x 1200 @
18bpp for LCD
I/O
z Storage EIDE x 1 (UDMA-100 for two
devices); SATA II x 2, Type II
CompactFlash x 1
z Serial Port RS-232 x 3,
RS-232/422/485 x 1
z USB Port USB2.0 x 4
z PS/2 Port Keyboard & Mouse x 1
z Digital I/O Supports 8-bit (Programmable)
z Audio Line-in, Line-out, Mic-in & CD-in
z TouchScreen Supports 4/5/8-wire
(Optional)
Chapter 1 General Information
1 - 5
