SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Connectors
Label Function
CN1 Audio Connector
CN2 AAEON Expansion Slot
CN3 Keyboard / Mouse Connector
CN4 USB Port 1,2 Connector
CN5 Touch Screen Connector
CN6 IDE Connector
CN7 RJ-45 Ethernet #2 Connector
CN8 RJ-45 Ethernet #1 Connector
CN9 USB Port 3,4 Connector
CN10 TV-out Connector
CN11 SATA 1 Connector
CN12 SATA 2 Connector
CN13 LVDS Connector
CN14 LCD Backlight Connector
CN15 COM Port 1 Connector
CN16 COM Port 2 Connector
CN17 COM Port 3 Connector
