SubCompact Board GENE-9455
1.3 Specifications
System
z Processor Onboard Intel
®
Atom™ N270
Processor 1.6GHz, FSB
533MHz
z System Memory 200-pin DDRII SODIMM x 1,
Max. 2GB (DDRII 400/533)
z Chipset Intel
®
945GSE + ICH7M
z I/O Chipset ITE8781
z Ethernet Intel
®
82574L,
10/100/100Base-TX, RJ-45 x 2
z BIOS Award Plug & Play SPI BIOS –
2MB Flash
z Watchdog Timer Generates a time-out system
reset
z H/W Monitor Chipset Supports power supply voltages
and temperature monitoring
z Expansion Interface Mini PCI x 1 & ECX Proprietary
Expansion x 1
z Battery Lithium battery
z Power Requirement +8.5V to +19V Wide DC Input
Range or +5V only
z Board Size 5.75”(L) x 4”(W) (146mm x
101.6mm)
Chapter 1 General Information 1- 4
