SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-22
2.33 DVI/CRT Display Connector (CN19) -Configured by
manufacturer
DVI Display
Pin Signal Pin Signal
C1 RED C2 GREEN
C3 BLUE C4 HSYNC
C5 Ground C6 N/C
1 DVI_TDC2# 2 DVI_TDC2
3 Ground 4 DDCCLK
5 DDCDATA 6 DVI_CLK
7 DVI_DATA 8 VSYNC
9 DVI_TDC1# 10 DVI_TDC1
11 Ground 12 N/C
13 N/C 14 +5 Volt.
15 Ground 16 DVI_DET
17 DVI_TDC0# 18 DVI_TDC0
19 Ground 20 N/C
21 N/C 22 Ground
23 DVI_TLC 24 DVI_TLC#
25 Ground 26 Ground
27 N/C 28 N/C
CRT Display
Pin Signal Pin Signal
29 DDCCLK 30 N/C
31 +5 Volt. 32 HSYNC
33 GREEN 34 Ground
35 N/C 36 Ground
