Aaeon GENE-9455 - Touch Screen Connector (CN5); IDE Connector (CN6)

SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-16
4 Ground 8 Ground
2.19 Touch Screen Connector (CN5)
Pin 8-wire Signal 4-wire Signal 5-wire Signal
1 Ground Ground Ground
2 Top Excite Top UL(Y)
3 Bottom Excite Bottom UR(H)
4 Left Excite Left LL(L)
5 Right Excite Right LR(X)
6 Top Sense N/C SENSE
7 Bottom Sense N/C N/C
8 Left Sense N/C N/C
9 Right Sense N/C N/C
2.20 IDE Connector (CN6)
Pin Signal Pin Signal
1 IDERST# 2 Ground
3 D7 4 D8
5 D6 6 D9
7 D5 8 D10
9 D4 10 D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 Ground 20 N/C /+5 Volt. For DOM optional
21 DREQ 22 Ground
23 IOW# 24 Ground
25 IOR# 26 Ground
27 IORDY 28 Ground
