Aaeon GENE-9455 - DDRII SODIMM Slot (DIMM1)

SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-26
11 Ground 36 +3.3 Volt.
12 Ground 37 INT_IRQ14
13 +3.3 Volt. 38 +3.3 Volt.
14 Ground 39 CSEL#
15 Ground 40 N/C
16 Ground 41 IDERST#
17 Ground 42 PIORDY
18 PDA2 43 N/C
19 PDA1 44 +3.3 Volt.
20 PDA0 45 DASP#
21 PDD0 46 PDIAG#
22 PDD1 47 PDD8
23 PDD2 48 PDD9
24 N/C 49 PDD10
25 Ground 50 Ground
2.42 Mini-PCI Slot (MPC1)
Standard Specification.
2.43 DDRII SODIMM Slot (DIMM1)
Standard Specification.
